VM-214DT – Protocol 3000
32
Protocol 3000
The can be operated using serial commands from a PC, remote controller or touch screen
using the Kramer Protocol 3000.
This section describes:
• Kramer Protocol 3000 syntax (see Kramer Protocol 3000 Syntax on page 32)
• Kramer Protocol 3000 commands (see Kramer Protocol 3000 Commands on page 35)
Kramer Protocol 3000 Syntax
Host Message Format
Start
Address (optional)
Body
Delimiter
#
Device_id@
Message
CR
Simple Command
Command string with only one command without addressing:
Start
Body
Delimiter
#
Command SP Parameter_1,Parameter_2,…
CR
Command String
Formal syntax with commands concatenation and addressing:
Start
Address
Body
Delimiter
#
Device_id@
Command_1 Parameter1_1,Parameter1_2,…|
Command_2 Parameter2_1,Parameter2_2,…|
Command_3 Parameter3_1,Parameter3_2,…|…
CR
Device Message Format
Start
Address (optional)
Body
Delimiter
~
Device_id@
Message
CR LF
Device Long Response
Echoing command:
Start
Address (optional)
Body
Delimiter
~
Device_id@
Command SP [Param1 ,Param2 …] result
CR LF
CR = Carriage return (ASCII 13 = 0x0D)
LF = Line feed (ASCII 10 = 0x0A)
SP = Space (ASCII 32 = 0x20)
