10 Related Documents KSB Delta Macro
77 of 92
1983.843/04-EN
Parameter Description Value range and dependencies Factory setting Access level Read Access level Write Re-start
required
2-7-1-4-1 Additional tank filling Disabled Disabled Everybody Service -
Enabled
2-7-1-4-2 Inlet valve type Tank filling additional solenoid valve Additional tank-
filling solenoid
valve
Everybody Service -
Tank filling proportional valve
2-7-1-4-3 Minimum opening angle of
valve
0 … 100 % 0,1 Everybody Service -
2-7-1-4-4 Step width for valve actuation 0 … 100 % 0,1 Everybody Service -
2-7-1-5 Drinking water protection - - - - -
2-7-1-5-1 Drinking water protection Disabled Enabled Everybody Service -
Enabled
2-7-1-5-2 Maximum time between usage
of drinking water
0… 31 d 168h Everybody Service -
2-7-1-5-3 Response Message only 0: Message only Everybody Service -
Message and flushing of inlet line
2-7-1-5-4 Time for flushing drinking water
supply
0 … 600s 10 s Everybody Service -
2-7-1-5-5 Overflow if high-water level is
exceeded
Not allowed Allowed without
message
Everybody Service -
Allowed with message
Allowed without message
2-7-2 Rainwater - - - - -
2-7-2-1 Rainwater filling - - - - -
2-7-2-1-1 Rainwater filling Disabled Disabled Everybody Service -
Enabled
2-7-2-2 Rainwater pumps - - Everybody Nobody -
2-7-2-2-1 Source for dry running
protection of rainwater pump
No function None Everybody Service -
Float switch at rainwater tank
2-7-2-2-3 Delay time for stop 0 … 99s 1s Everybody Service -
2-7-2-2-4 Delay time reset 0 … 99s 1s Everybody Service -
2-7-2-2-5 Number of rainwater pumps 1 … 2 0 Everybody Service -
2-7-2-2-8 Maximum runtime 0 … 3600s 60s Everybody Service -
2-7-2-2-9 Changeover delay 0 …. 60s 1s Everybody Service -
2-7-2-2-10 Maximum number of pump
starts per hour
1/h…20/h 20/h Everybody Service -
