KSB Delta Macro

1983.843/04-EN

Parameter Description Value range and dependencies Factory setting Access level Read Access level Write Re-start

required

2-7-2-3 Tank level - - Everybody Nobody -

2-7-2-3-1 Start level for rainwater tank

filling

Start tank filling level drinking water

… stop tank filling level rainwater

0,6 Everybody Service -

2-7-2-3-2 Stop level for rainwater tank

filling

Start tank filling level rainwater …

high-water level

1 Everybody Service -

10.2.2.8 Control algorithms

Table36: Control algorithms parameters

Parameter Description Value range and dependencies Factory setting Access level Read Access level Write Re-start

required

2-8 Control algorithms - - Service Nobody -

2-8-1 PID controller - - - - -

2-8-1-1 Proportional constant Value range according to controller 5 Service Service -

2-8-1-2 Integral constant Value range according to controller 0 Service Service -

2-8-1-3 Differential constant Value range according to controller 0 Service Service -

2-8-2 Input signals - - Service Nobody -

2-8-2-1 Damping factor Value range according to controller TBD Service Service -

2-8-3 System start-up time delay - - - - -

2-8-3-1 System start-up time delay 0 … 60 s 10 s Service Service -

2-8-4 Multi-pump operation - - - - -

2-8-4-1 Start flow rate 0 .. 100 % 0,95 Service Service -

2-8-4-2 Speed on percent 0 .. 140% 1 Service Service -

2-8-4-3 Speed off percent 0 .. 90% 0,5 Service Service -

2-8-4-4 Pump dynamic control 1 .. 100 % 0,3 Service Service -

10.2.2.9 Display

Table37: Display parameters

Parameter Description Value range and dependencies Factory setting Access level Read Access level Write Re-start

required

2-10 Access - - Everybody Nobody -

2-10-1 Display - - Everybody Nobody -
