KTM 1050 Adventure User Manual

15 WHEELS, TIRES 141
M00936-10
–
Mount wheel spindle

but do not push it in all the way.
– Push the rear wheel as far forward as possible and place the chain on the rear sprocket.
M00919-10
–
Push the wheel spindle in all the way and mount the chain adjuster

and nut

.
Info
Mount chain adjusters

and

in the same position.
– Make sure that the chain adjusters are fitted correctly on the adjusting screws.
Guideline
In order for the rear wheel to be correctly aligned, the markings on the left and right
chain adjusters must be in the same position relative to the reference marks

.
–
Tighten nut

.
Guideline
Nut, rear wheel spindle M25x1.5 90 Nm
(66.4 lbf ft)
Thread greased

KTM 1050 Adventure Specifications

General

Displacement	1050 cc
Transmission	6-speed
Fuel Tank Capacity	23 liters
Seat Height	850 mm
Bore x Stroke	103 mm x 63 mm
Fuel System	Electronic Fuel Injection
Cooling System	Liquid cooled
ABS	Bosch 9M+ two-channel ABS
Compression Ratio	12.5:1
Starter	Electric
Engine Type	2-cylinder, 4-stroke
Power	95 hp
Torque	107 Nm
Front Suspension	WP USD, 43 mm
Rear Suspension	WP monoshock
Front Brake	4-piston calipers
Rear Brake	267 mm disc, 2-piston caliper
Frame	Chromium-Molybdenum steel trellis
Front Wheel	19 inch
Rear Wheel	17 inch
Dry Weight	212 kg (467 lbs)
