16 ELECTRICAL SYSTEM 154
16.5 Changing the main fuse
Warning
Fire hazard The electrical system can be overloaded if the wrong fuses are used.
– Use only fuses with the prescribed amperage. Never bypass or repair fuses.
Preparatory work
– Switch off all power consumers and switch off the engine.
– Remove the seat. ( p. 97)
M00940-10
Main work
–
Remove screws
.
–
Raise rear fairing
slightly.
M00941-10
–
Remove protection caps
.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KTM 1050 Adventure and is the answer not in the manual?

KTM 1050 Adventure Specifications

General IconGeneral
Displacement1050 cc
Transmission6-speed
Fuel Tank Capacity23 liters
Seat Height850 mm
Bore x Stroke103 mm x 63 mm
Fuel SystemElectronic Fuel Injection
Cooling SystemLiquid cooled
ABSBosch 9M+ two-channel ABS
Compression Ratio12.5:1
StarterElectric
Engine Type2-cylinder, 4-stroke
Power95 hp
Torque107 Nm
Front SuspensionWP USD, 43 mm
Rear SuspensionWP monoshock
Front Brake4-piston calipers
Rear Brake267 mm disc, 2-piston caliper
FrameChromium-Molybdenum steel trellis
Front Wheel19 inch
Rear Wheel17 inch
Dry Weight212 kg (467 lbs)
