KTM 1050 Adventure User Manual

23 TECHNICAL DATA 195
Screw, bearing shells retaining bracket M5 6 Nm (4.4 lbf ft) Loctite
®
243™
Screw, engine oil level viewer M5 4 Nm (3 lbf ft) –
Screw, gear sensor M5 6 Nm (4.4 lbf ft) Loctite
®
243™
Screw, pulse generator M5 6 Nm (4.4 lbf ft) Loctite
®
243™
Bleeder screw, water pump cover M6 10 Nm (7.4 lbf ft) –
Freewheel ring bolt M6 – 10.9 15 Nm (11.1 lbf ft) Loctite
®
648™
Nut, cylinder head M6 9 Nm (6.6 lbf ft) –
Plug, vacuum connection M6 5 Nm (3.7 lbf ft) Loctite
®
243™
Remaining engine screws M6 10 Nm (7.4 lbf ft) –
Screw, camshaft bearing support M6 – 10.9 10 Nm (7.4 lbf ft) –
Screw, clutch cover M6 10 Nm (7.4 lbf ft) –
Screw, clutch spring M6 12 Nm (8.9 lbf ft) –
Screw, coolant connection on cylinder
head
M6 10 Nm (7.4 lbf ft) –
Screw, engine case M6x60 10 Nm (7.4 lbf ft) –
Screw, engine case M6x80 10 Nm (7.4 lbf ft) –
Screw, engine case M6x90 10 Nm (7.4 lbf ft) –
Screw, freewheel holder M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, locking lever M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, oil pump cover M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, shift drum locating M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, shift lever M6 18 Nm (13.3 lbf ft) Loctite
®
243™
Screw, starter motor M6 10 Nm (7.4 lbf ft) –
Screw, stator M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, valve cover M6 10 Nm (7.4 lbf ft) –

KTM 1050 Adventure Specifications

General

Displacement	1050 cc
Transmission	6-speed
Fuel Tank Capacity	23 liters
Seat Height	850 mm
Bore x Stroke	103 mm x 63 mm
Fuel System	Electronic Fuel Injection
Cooling System	Liquid cooled
ABS	Bosch 9M+ two-channel ABS
Compression Ratio	12.5:1
Starter	Electric
Engine Type	2-cylinder, 4-stroke
Power	95 hp
Torque	107 Nm
Front Suspension	WP USD, 43 mm
Rear Suspension	WP monoshock
Front Brake	4-piston calipers
Rear Brake	267 mm disc, 2-piston caliper
Frame	Chromium-Molybdenum steel trellis
Front Wheel	19 inch
Rear Wheel	17 inch
Dry Weight	212 kg (467 lbs)
