KTM 1090 ADVENTURE 2017 User Manual

15 WHEELS, TIRES 147
15.4 Installing the rear wheel
Warning
Danger of accidents Oil or grease on the brake discs reduces the braking effect.
– Always keep the brake discs free of oil and grease.
– Clean the brake discs with brake cleaner when necessary.
Warning
Danger of accidents There is no braking effect to start with at the rear brake after installing the rear wheel.
– Actuate the foot brake several times before going on a ride until you can feel a firm pressure point.
Main work
– Check the rear hub rubber dampers. ( p. 149)
D03109-10
– Check the wheel bearing for damage and wear.
» If the wheel bearing is damaged or worn:
– Change the rear wheel bearing.
–
Clean and grease shaft seal ring
1
and contact surface
A
of the spacer.
Long-life grease ( p. 219)
– Clean and grease the thread of the wheel spindle and nut.
Long-life grease ( p. 219)
– Install the rubber dampers and rear sprocket carrier on the rear wheel.
– Place the rear wheel in the swingarm and bring the brake disc into contact with the
brake caliper.

KTM 1090 ADVENTURE 2017 Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1050 cc
Torque	109 Nm @ 6500 rpm
Transmission	6-speed
Fuel Tank Capacity	23 liters
Seat Height	850 mm
Dry Weight	205 kg
Front Suspension	WP USD Ø 48 mm
Fuel System	Electronic Fuel Injection
Bore x Stroke	103 mm x 63 mm
Compression Ratio	13.0:1
Starter	Electric starter
Power	92 kW (125 hp) @ 8500 rpm
Rear Suspension	WP monoshock
Front Brake	2 x Brembo 320 mm discs, 4-piston radial calipers
Rear Brake	Brembo 267 mm disc, 2-piston caliper
ABS	Bosch 9M+ two-channel ABS
Cooling	Liquid cooled
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Tire	120/70 R19
Rear Tire	150/70 R17
