7 COMBINATION INSTRUMENT 44
7.3 Matrix display
F00706-01
The matrix display is controlled using the menu switch ( p. 29).
After the ignition is switched on, the display shows when the next service ( p. 48) is due.
If the General warning lamp lights up among the indicator lamps ( p. 45), the corre-
sponding message appears in the matrix display. The SET button is used to confirm receipt
of the information and the message is cleared.
Messages appear 10 s
7.4 Segment display
M00865-10
1 Fuel level display ( p. 45)
2 Time symbol
3 Unit for the speedometer
4 Gear display
5 Speed
6 "Drive Mod" ( p. 185)
7 Time
8 Coolant temperature
9 Ice warning
