19 SERVICE WORK ON THE ENGINE 189
F00701-11
–
Remove screws
2
. Remove oil filter cover
3
with the O-ring.
F00702-10
–
Pull oil filter
4
out of the oil filter housing.
Circlip pliers reverse (51012011000)
– Completely drain the engine oil.
– Thoroughly clean the parts and sealing surface.
F00703-10
–
Insert oil filter
4
.
Info
Only insert the oil filter by hand.
–
Lubricate the O-ring of the oil filter cover. Mount oil filter cover
3
.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KTM 1090 ADVENTURE 2017 and is the answer not in the manual?

KTM 1090 ADVENTURE 2017 Specifications

General IconGeneral
Engine Type2-cylinder, 4-stroke, V 75°
Displacement1050 cc
Torque109 Nm @ 6500 rpm
Transmission6-speed
Fuel Tank Capacity23 liters
Seat Height850 mm
Dry Weight205 kg
Front SuspensionWP USD Ø 48 mm
Fuel SystemElectronic Fuel Injection
Bore x Stroke103 mm x 63 mm
Compression Ratio13.0:1
StarterElectric starter
Power92 kW (125 hp) @ 8500 rpm
Rear SuspensionWP monoshock
Front Brake2 x Brembo 320 mm discs, 4-piston radial calipers
Rear BrakeBrembo 267 mm disc, 2-piston caliper
ABSBosch 9M+ two-channel ABS
CoolingLiquid cooled
FrameChromium-Molybdenum steel trellis frame, powder coated
Front Tire120/70 R19
Rear Tire150/70 R17
