KTM 1090 ADVENTURE 2017 User Manual

22 TROUBLESHOOTING 202
Faults Possible cause Action
Engine turns but does not start Fault in fuel injection system – Read out the fault memory using the KTM diag-
nostics tool.
Fuel quality is insufficient – Add suitable fuel.
Engine dies during the trip Lack of fuel – Refuel. ( p. 89)
Fault in fuel injection system – Read out the fault memory using the KTM diag-
nostics tool.
The engine warning lamp lights
up/flashes
Fault in fuel injection system – Read out the fault memory using the KTM diag-
nostics tool.
The ABS warning lamp lights up ABS fuse is blown – Change the fuses in the fuse box. ( p. 165)
Wheel speeds of front and rear wheels
differ greatly
– Stop, switch off the ignition, start again.
Malfunction in ABS – Read out the fault memory using the KTM diag-
nostics tool.
High oil consumption Engine oil level too high – Check the engine oil level. ( p. 187)
Engine oil too thin (low viscosity) – Change the engine oil and oil filter and clean the
oil screens. ( p. 188)
The battery is discharged The hazard warning flasher is switched
on
– Switch off the hazard warning flasher.
– Recharge the battery. ( p. 159)
Battery is not charged by alternator – Check the charging voltage.
Ignition was not switched off when
vehicle was parked
– Recharge the battery. ( p. 159)

KTM 1090 ADVENTURE 2017 Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1050 cc
Torque	109 Nm @ 6500 rpm
Transmission	6-speed
Fuel Tank Capacity	23 liters
Seat Height	850 mm
Dry Weight	205 kg
Front Suspension	WP USD Ø 48 mm
Fuel System	Electronic Fuel Injection
Bore x Stroke	103 mm x 63 mm
Compression Ratio	13.0:1
Starter	Electric starter
Power	92 kW (125 hp) @ 8500 rpm
Rear Suspension	WP monoshock
Front Brake	2 x Brembo 320 mm discs, 4-piston radial calipers
Rear Brake	Brembo 267 mm disc, 2-piston caliper
ABS	Bosch 9M+ two-channel ABS
Cooling	Liquid cooled
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Tire	120/70 R19
Rear Tire	150/70 R17
