23 TECHNICAL DATA 213
Remaining chassis screws M10 45 Nm (33.2 lbf ft) –
Screw, front brake caliper M10 45 Nm (33.2 lbf ft) Loctite
®
243™
Screw, handlebar support M10 40 Nm (29.5 lbf ft) Loctite
®
243™
Screw, side stand M10 35 Nm (25.8 lbf ft) Loctite
®
243™
Screw, side stand bracket M10 45 Nm (33.2 lbf ft) Loctite
®
243™
Banjo bolt, brake line M10x1 25 Nm (18.4 lbf ft) –
Nut, tire pressure sensor M10x1 12 Nm (8.9 lbf ft) Loctite
®
243™
Screw, subframe M10x1.25 45 Nm (33.2 lbf ft) –
Lambda sensor M12x1.25 25 Nm (18.4 lbf ft) –
Screw, bottom shock absorber M14x1.5 80 Nm (59 lbf ft) Thread greased
Screw, top shock absorber M14x1.5 80 Nm (59 lbf ft) Thread greased
Nut, socket M18x1 4 Nm (3 lbf ft) –
Nut, swingarm pivot M19x1.5 130 Nm (95.9 lbf ft) Thread greased
Screw, steering head, top M22x1.5 50 Nm (36.9 lbf ft) –
Nut, rear wheel spindle M25x1.5 90 Nm (66.4 lbf ft) Thread greased
Screw, front wheel spindle M25x1.5 45 Nm (33.2 lbf ft) Thread greased
Nut, steering head, top M28x1.0 12 Nm (8.9 lbf ft) –

KTM 1190 ADVENTURE R Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Transmission	6-speed
Fuel Capacity	23 liters
Dry Weight	217 kg
Front Suspension	WP USD Ø 48 mm
Wheelbase	1560 mm
Compression Ratio	12.5:1
Starter	Electric starter
Cooling	Liquid cooled
Lubrication	Forced oil lubrication with 3 oil pumps
Primary Drive	40:76
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Suspension Travel Front	220 mm
Suspension Travel Rear	220 mm
Ground Clearance	250 mm
Power	110 kW (150 hp)
Torque	125 Nm
Front Brake	2 x Brembo four-piston, radially mounted caliper, brake disc Ø 320 mm
Rear Brake	Brembo 2-piston caliper, 267 mm disc
ABS	Bosch 9ME Combined-ABS
Seat Height	890 mm (35 in)
Final Drive	Chain
Clutch	PASC (Power Assisted Slipper Clutch), hydraulically operated
