7 COMBINATION INSTRUMENT 49
7.3 Matrix display
401821-01
The matrix display is controlled using the menu switch ( p. 35).
After the ignition is switched on, the display shows when the next service ( p. 53) is due.
If the General warning lamp lights up among the indicator lamps ( p. 50), the corre-
sponding message appears in the matrix display. The Set button is used to confirm receipt
of the information and the message is cleared.
Messages appear 10 s
7.4 Segment display
401854-10
1 Fuel level
2 Time
3 Unit for the speedometer
4 Gear display
5 Speed
6 "Drive Mode" ( p. 182)
7 Coolant temperature
8 No function
9 Ice warning

KTM 1190 ADVENTURE R Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Transmission	6-speed
Fuel Capacity	23 liters
Dry Weight	217 kg
Front Suspension	WP USD Ø 48 mm
Wheelbase	1560 mm
Compression Ratio	12.5:1
Starter	Electric starter
Cooling	Liquid cooled
Lubrication	Forced oil lubrication with 3 oil pumps
Primary Drive	40:76
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Suspension Travel Front	220 mm
Suspension Travel Rear	220 mm
Ground Clearance	250 mm
Power	110 kW (150 hp)
Torque	125 Nm
Front Brake	2 x Brembo four-piston, radially mounted caliper, brake disc Ø 320 mm
Rear Brake	Brembo 2-piston caliper, 267 mm disc
ABS	Bosch 9ME Combined-ABS
Seat Height	890 mm (35 in)
Final Drive	Chain
Clutch	PASC (Power Assisted Slipper Clutch), hydraulically operated
