13 WHEELS, TIRES 104
13.3 Removing the rear wheel x
Preparatory work
– Raise the motorcycle with the rear wheel stand. ( p. 74)
B01606-10
Main work
(Option: Without ABS)
–
Remove nut
and the washer. Remove chain adjuster
.
–
Holding the rear wheel, withdraw wheel spindle
with the washer and chain
adjuster
.
– Push the rear wheel forward as far as possible and take the chain off the rear
sprocket.
Warning
Danger of accidents Reduced braking effect caused by damaged brake
discs.
– Always lay the wheel down in such a way that the brake discs are not
damaged.
– Pull the rear wheel back and take it out of the swingarm.
Info
Do not operate the foot brake when the rear wheel is removed.
