21 TECHNICAL DATA 160

Fitted length 300 mm (11.81 in)

21.9 Chassis tightening torques

Screw, chain guard EJOT PT

4 Nm (3 lbf ft) –

Screw, headlight EJOT PT

4 Nm (3 lbf ft) –

Remaining screws, chassis M4 4 Nm (3 lbf ft) –

Screw, EFI control unit M4 4 Nm (3 lbf ft) –

Screw, trim, subframe, bottom M4 2 Nm (1.5 lbf ft) –

Remaining screws, chassis M5 5 Nm (3.7 lbf ft) –

Screw, brake fluid reservoir of rear brake M5 6 Nm (4.4 lbf ft) Loctite

243™

Screw, brake line holder, rear M5 8 Nm (5.9 lbf ft) Loctite

243™

Screw, fuel pump M5 5 Nm (3.7 lbf ft) –

Screw, fuel tank closure flange M5 3 Nm (2.2 lbf ft) –

Screw, fuel tank cover M5 4 Nm (3 lbf ft) –

Screw, fuel tank trim M5 5 Nm (3.7 lbf ft) –

Screw, license plate holder M5 11 Nm (8.1 lbf ft) –

Screw, rollover sensor M5 6 Nm (4.4 lbf ft) Loctite

243™

Screw, side stand switch M5 5 Nm (3.7 lbf ft) Loctite

243™

Screw, spoiler M5 5 Nm (3.7 lbf ft) –

Screw, subframe cover, bottom M5 5 Nm (3.7 lbf ft) Loctite

243™

Screw, windshield M5 3 Nm (2.2 lbf ft) –

Nut, foot brake lever adjustment M6 10 Nm (7.4 lbf ft) –

Nut, radiator M6 5 Nm (3.7 lbf ft) –

Remaining nuts, chassis M6 15 Nm (11.1 lbf ft) –
