TECHNICAL DATA 22
141
Screw, oil filter cover M6 10 Nm (7.4 lbf ft)
Screw, shift drum locating M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift lever M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, starter motor M6 10 Nm (7.4 lbf ft)
Screw, starter motor - intermediate
gear
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, timing chain failure protec-
tion
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, valve cover M6 8 Nm (5.9 lbf ft)
Screw, water pump cover M6 10 Nm (7.4 lbf ft)
Stud, cylinder head M6 10 Nm (7.4 lbf ft)
Screw, auto decompression M7x1 15 Nm (11.1 lbf ft)
Loctite
®
243™
Screw, camshaft bearing bridge M7x1 Tightening sequence:
Tighten diagonally.
1st tightening stage
5 Nm (3.7 lbf ft)
2nd tightening stage
14 Nm (10.3 lbf ft)
Lubricated with engine oil
Crankshaft clamp screw plug M8 10 Nm (7.4 lbf ft)
Screw, tensioning rail M8 15 Nm (11.1 lbf ft)
Loctite
®
243™
Screw, engine sprocket M10 60 Nm (44.3 lbf ft)
Loctite
®
243™
Plug, oil channel M10x1 15 Nm (11.1 lbf ft)
Loctite
®
243™
Screw plug, cam lever axis M10x1 10 Nm (7.4 lbf ft)
Screw, rotor M10x1 70 Nm (51.6 lbf ft)
Collar and thread oiled / cone
degreased
Screw, unlocking of timing chain
tensioner
M10x1 8 Nm (5.9 lbf ft)
Spark plug M10x1 12 Nm (8.9 lbf ft)
Coolant temperature sensor M10x1.25 12 Nm (8.9 lbf ft)
Nut, cylinder head M10x1.25 Tightening sequence:
Tighten diagonally.
1st tightening stage
10 Nm (7.4 lbf ft)
2nd tightening stage
30 Nm (22.1 lbf ft)
3rd tightening stage
180°
Stud, cylinder head M10x1.25 20 Nm (14.8 lbf ft)
Loctite
®
243™
Oil drain plug with magnet M12x1.5 20 Nm (14.8 lbf ft)
Screw plug, oil pressure control
valve
M12x1.5 20 Nm (14.8 lbf ft)
Oil drain plug M14x1.5 15 Nm (11.1 lbf ft)
