11 SERVICE WORK ON THE CHASSIS 49
S01268-11
–
Pull off the air filter box cover in area
A
sideways and remove it toward
the front.
S01253-10
(XC‑F US)
Condition
The air filter box cover is secured.
–
Remove screw
1
.
S01254-10
–
Pull off the air filter box cover in area
A
sideways and remove it toward
the front.
11.23 Installing the air filter box cover
S01268-12
(All SX‑F models)
–
Insert the air filter box cover in area
A
and clip it into area
B
.
S01268-10
Condition
The air filter box cover is secured.
–
Mount and tighten screw
1
.
Guideline
Screw, air filter box cover EJOT PT
®
K60x20-Z
3 Nm
(2.2 lbf ft)
S01254-11
(XC‑F US)
–
Insert the air filter box cover in area
A
and clip it into area
B
.
