6 CONTROLS 15
6.13 Idle speed adjusting screw
C00245-10
The idle setting of the throttle valve body has a big influence on the starting behavior,
stable idling and the response to throttle opening. This means that an engine with a
correctly set idle speed is easier to start than if the idle is set wrongly.
The idle speed is adjusted with idle speed adjusting screw 1.
Turning the adjusting screw clockwise increases the idle speed.
Turning the adjusting screw counterclockwise lowers the idle speed.
6.14 Shift lever
601839-12
Shift lever 1 is mounted on the left side of the engine.
601839-10
(All USA models, SX‑F Factory Edition)
The gear positions can be seen in the photograph.
The neutral or idle position is between the first and second gears.
C00221-10
(450 SX‑F EU)
The gear positions can be seen in the photograph.
The neutral or idle position is between the first and second gears.
