Repair manual KTM 250 / 300 / 380 Art No 3206004 -E
9-16C
VERGASERREGULIERUNG
KTM 250 MXC/EXC EUR/USA 2000 KEIHIN PWK 38
AG
CARBURETOR SETTING
-20°C bis -7°C -6°C bis 5°C 6°C bis 15°C 16°C bis 24°C 25°C bis 38°C 37°C bis 49°C
-2°F to 20°F 19°F to 41°F 42°F to 60°F 61°F to 78°F 79°F to 98°F 99°F to 120°F
TEMPERATURMEERESHÖHE
ALTIDUDE
LSCHR AS 1 3/4 1 3/4 1 3/4 2 2 1/2 1 3/4 LD IJ 40 40 40 38 38 38 NADEL
NEEDLE
NOZH NOZH NOZH NOZI NOZI NOZI
POS POS 332222 HD MJ 178 175 172 170 170 168 LSCHR AS 1 1/4 1 1/2 1 3/4 1 3/4 2 2 LD IJ 42 42 40 40 40 40 NADEL
NEEDLE
NOZG NOZG NOZH NOZH NOZI NOZI
POS POS 332222 HD MJ 180 178 175 172 170 168 LSCHR AS 1 1/4 1 1/2 1 1/2 1 3/4 1 3/4 2 LD IJ 45 45 42 42 42 40 NADEL
NEEDLE
NOZG NOZG NOZG NOZH NOZI NOZI
POS POS 433222 HD MJ 182 180 178 175 172 170 LSCHR AS 1 1/4 1 1/4 1 1/4 1 1/2 1 3/4 1 3/4 LD IJ 45 45 45 42 42 42 NADEL
NEEDLE
NOZF NOZG NOZG NOZG NOZH NOZH
POS POS 443332 HD MJ 185 182 180 178 175 172 LSCHR AS 11 1/41 1/2 1 1/4 1 1/2 1 3/4 LD IJ 50 48 45 45 42 42 NADEL
NEEDLE
NOZE NOZF NOZG NOZG NOZH NOZH
POS POS 543332 HD MJ 188 185 182 180 178 175
3000 m
10000 ft
2301 m
7501 ft
2300 m
7500 ft
1501 m
5001 ft
1500 m
5000 ft
751 m
2501 ft
750 m
2500 ft
301 m
1001 ft
300 m
1000 ft
Meeresniveau
Sea level
LSCHR = Luftregulierschraube offen LD = Leerlaufdüse POS = Clip Position von oben HD = Hauptdüse
AS = Air screw open from fully-seated IJ = Idling jet POS = Clip position from top MJ = Main jet
NICHT FÜR STRASSENBETRIEB Kraftstoff: Euro-Super bleifrei ROZ 95 NOT FOR HIGHWAY USE Fuel: Euro-Super unleaded ROZ 95
21.06.99
1. 3. 5.
2. 4.

KTM EXC Specifications

General

Ignition	Kokusan
Starter	Kickstarter
Transmission	6-speed
Engine Type	Single Cylinder, 2-Stroke
Cooling	Liquid Cooled
Lubrication	Premix
