WHEELS, TIRES 14
155
E00641-11
– Position the chain guard.
–
Mount and tighten screw
7
.
Guideline
Screw, chain guard M6 6 Nm (4.4 lbf ft)
–
Mount and tighten screw
8
.
Guideline
Screw, chain guard EJOT PT
®
K60x30
4 Nm (3 lbf ft)
Finishing work
– Check the chain tension. ( p. 112)
– Remove the rear of the motorcycle from the lifting gear.
( p. 100)
14.5 Checking the rear hub damping rubber pieces
Info
The engine power is transmitted from the rear sprocket to the rear wheel via the 6 damping rubber pieces.
They eventually wear out during operation. If the damping rubber pieces are not changed in time, the rear
sprocket carrier and the rear hub will be damaged.
Preparatory work
– Raise the motorcycle with the rear lifting gear. ( p. 100)
– Remove the rear wheel. ( p. 150)
