15 ELECTRICAL SYSTEM

182

15.12 Diagnostics connector

H01911-10

Diagnostics connector

is located under the front rider's seat.

15.13 Front ACC1 and ACC2

F01484-10

Installation location

–

Power supplies ACC1

and ACC2

front are located

under the compensating tank.

Info

The power supplies are protected by a fuse, however this

fuse also protects other power consumers.

The maximum continuous load is therefore significantly

lower than the value of the fuse.

Do not use a stronger fuse.
