ELECTRICAL SYSTEM 15
167
– Set the clock. ( p. 68)
15.4 Changing the ABS fuses
Warning
Fire hazard Incorrect fuses overload the electrical system.
– Only use fuses with the required ampere value.
– Do not bypass or repair fuses.
Info
Two fuses for the ABS are located under the protection cap next to the negative terminal of the 12-V bat-
tery. These fuses protect the return pump and the hydraulic unit of the ABS. The third fuse, which pro-
tects the ABS control unit, is located in the fuse box.
Preparatory work
– Switch off the ignition by turning the ignition key to the posi-
tion .
– Remove the front rider's seat. ( p. 106)
– Remove the battery cover. ( p. 118)
