23 TECHNICAL DATA 185
Chain 5/8 x 1/4” (520) O‑ring
Steering head angle 66.5°
Wheelbase 1,340±15 mm (52.76±0.59 in)
Seat height, unloaded 820 mm (32.28 in)
Ground clearance, unloaded 178 mm (7.01 in)
Weight without fuel, approx. (RC 125) 140 kg (309 lb.)
Weight without fuel, approx. (RC 200) 141.5 kg (312 lb.)
Maximum permissible front axle load 125 kg (276 lb.)
Maximum permissible rear axle load 210 kg (463 lb.)
Maximum permissible overall weight 335 kg (739 lb.)
23.5 Electrical system
Battery ETZ-9-BS Battery voltage: 12 V
Nominal capacity: 8 Ah
Maintenance-free
Fuse (RC 125) 75011088005 5 A
Fuse 75011088010 10 A
Fuse 75011088015 15 A
Fuse 90111088025 25 A
Fuse 75011088030 30 A
Low beam H11 / Sockel PGJ19-2 12 V
55 W
High beam H11 / Sockel PGJ19-2 12 V
55 W
Parking light LED
