23 TECHNICAL DATA 187

Sport 4 clicks

Full payload 8 clicks

Static sag 14 mm (0.55 in)

Riding sag 45… 50 mm (1.77… 1.97 in)

Fitted length 300 mm (11.81 in)

23.9 Chassis tightening torques

Exhaust clamp - 10 Nm (7.4 lbf ft) –

Screw, chain guard EJOT PT

K60x30 4 Nm (3 lbf ft) –

Remaining nuts, chassis M4 3 Nm (2.2 lbf ft) –

Remaining screws, chassis M4 3 Nm (2.2 lbf ft) –

Screw, EFI control unit M4 3 Nm (2.2 lbf ft) –

Nut, reflector on retaining plate M5 7 Nm (5.2 lbf ft) –

Nut, retaining plate on license plate

holder

M5 4 Nm (3 lbf ft) –

Remaining nuts, chassis M5 5 Nm (3.7 lbf ft) –

Remaining screws, chassis M5 5 Nm (3.7 lbf ft) –

Screw, ABS hose clamp (RC 125) M5 6 Nm (4.4 lbf ft) –

Screw, anti-rotation lock, handlebar stub M5 4 Nm (3 lbf ft) –

Screw, battery compartment M5 4 Nm (3 lbf ft) –

Screw, chain guard M5 7 Nm (5.2 lbf ft) Loctite

204™

Screw, cover in front of battery compart-

ment

M5 4 Nm (3 lbf ft) –

Screw, fuel pump M5 5 Nm (3.7 lbf ft) –

Screw, fuel tank cover M5 5 Nm (3.7 lbf ft) –
