UNIVERSAL SYMBOLS
As a guide to the operation of your tractor, various universal symbols have been utilized on the instruments and
controls. The symbols are shown below with an indication of their meaning.
Safety Alert Symbol
Diesel Fuel
Fuel-Level
Engine-Rotational Speed
Hourmeter/Elapsed Operating Hours
Engine Coolant-Temperature
Clutch
Brake
Parking Brake
Battery Charging Condition
Engine Oil-Pressure
Turn Signal
Engine-Stop
Engine-Run
Diesel Preheat/Glow Plugs
(Low Temperature Start Aid)
Starter Control
Power Take-Off Clutch Control-Off Position
Power Take-Off Clutch Control-On Position
Differential Lock
Position Control-Raised Position
Position Control-Lowered Position
Draft Control-Shallow Position
Draft Control-Deep Position
3-Point Lowering Speed Control
Remote Cylinder-Retract
Remote Cylinder-Extend
Lock
Unlock
Hazard Warning Lights
Master Lighting Switch
Headlight
4-Wheel Drive-On
4-Wheel Drive-Off
Fast
Slow
Read Operator's Manual
Engine Speed Control
