1. Check wheel bolts and nuts regularly especially
when new.
2. If they are loose, tighten them as follows.
(1) Bolt (front wheel) (2) Bolt (rear wheel)
Tightening tor-
que
Bolt (front wheel)
(1)
79 N⋅m to 92 N⋅m
(8.1 kgf⋅m to 9.4 kgf⋅m)
[58.3 lbf⋅ft to 67.9 lbf⋅ft]
Bolt (rear wheel)
(2)
145 N⋅m to 150 N⋅m
(14.8 kgf⋅m to
15.3 kgf⋅m)
[107.0 lbf⋅ft to
110.6 lbf⋅ft]
4. Checking dust covers (tie-rod,
drag-link)
1. Check to see that dust covers are not damaged.
2. If dust covers are damaged, replace them at once.
(1) Dust covers (tie-rod: both
sides)
(2) Dust covers (drag-link: both
sides)
5. Checking lower link set bolt
1. Make sure the lower link set bolt is tight enough.
(1) Set bolt
(2) Lock nut
Tightening tor-
que
Set bolt (1)
15 N⋅m to 20 N⋅m
(1.6 kgf⋅m to 2.1 kgf⋅m)
[11.1 lbf⋅ft to 14.6 lbf⋅ft]
Lock nut (2)
43 N⋅m to 47 N⋅m
(4.4 kgf⋅m to 4.8 kgf⋅m)
[31.7 lbf⋅ft to 34.7 lbf⋅ft]
EVERY 100 HOURS
1. Battery
DANGER
To avoid the possibility of battery explosion:
For the refillable type battery, follow the following
instructions.
• Do not use or charge the refillable type battery
if the fluid level is below the “LOWER” (lower
limit level) mark. Otherwise, the battery
component parts may prematurely deteriorate,
which may shorten the battery's service life or
cause an explosion. Check the fluid level
regularly and add distilled water as required so
that the fluid level is between the “UPPER” and
“LOWER” levels.
WARNING
To avoid personal injury or death:
• Keep electrolyte away from eyes, hands and
clothes. If you are spattered with it, wash it
away completely with water immediately and
get medical attention.
• Wear eye protection and rubber gloves when
working around the battery.
• Never remote the vent caps while the engine is
running.
NOTE :
• The factory-installed battery is of non-refillable
type.
PERIODIC SERVICE EVERY 50 HOURS
B2401DT, B2401DTWO, B2401DTN
