Model BX23S
Dimensions
Min. ground clearance
148 mm
(5.83 in.)
Tread
Front
930 mm
(36.6 in.)
Rear
820 mm
(32.2 in.)
Weight (with ROPS)
725 kg
(1600 lbs.)
Clutch N / A
Traveling
system
Tire
Front 18 x 8.50-10 (Turf, Bar, Ind.)
Rear 26 x 12.00-12 (Turf, Bar, Ind.)
Steering Hydrostatic type power steering
Transmission Main: Hydrostatic transmission, High-Low gear shift (2 forward, 2 reverse)
Brake Wet disk type
Min. turning radius
2.3 m
(7.5 feet)
Hydraulic unit
Hydraulic control system Directional control, auto-return lever system
Pump capacity
23.5 L/min.
(6.2 gals/min.)
System pressure
12.3 MPa to 12.8 MPa
(126 kgf/cm
2
to 130 kgf/cm
2
)
[1790 psi to 1850 psi]
Three point hitch SAE Category 1 (Optional)
Three point hitch
Max. lift force
*3
At lift points
5390 N
(1210 lbs.)
24in. behind lift
points
3040 N
(680 lbs.)
Remote control valve
coupler (rear: Option)
System 2 valves
Coupler ISO 7241-1 series A
Remote control valve
coupler (front: Option)
System 2 valves
Coupler (fitting) ISO 7241-1 series B
PTO
Rear PTO
SAE 1-3/8, 6 splines
Revolution STD (2500 rpm)
Mid PTO
USA No.5 (KUBOTA 10-tooth) involute spline
Revolution STD (2500 rpm)
The company reserves the right to change the specifications without notice.
*1 Manufacturer's estimate
*2
SAE J1995
*3 See and check IMPLEMENT LIMITATION TABLES on page 40.
SPECIFICATIONS OF THE TRACTOR
