OPERATING THE LOADER66
5. Keeping the attachment at ground level, move the
loader control lever to the "roll back" position until the
cylinders stop. Turn off the engine and set the parking
brake.
6. Install both Hitch Pins and Snapper Pins as shown in
the following illustration.
The illustration shows a properly attached bucket.
To avoid personal injury:
A Make sure both hitch pins and snapper pins are
properly installed before moving or operating
attachments.
A Keep hitch pins and snapper pins assembled in
the BX6315 or LA243A AU-SG quick coupler at
all times, even if no attachment is being used.
A Replace any pins or other parts which are lost
or broken.
7. You are now ready to use the attached attachment.
Compatible attachments can be attached and
detached using the same method.
To avoid personal injury:
A Never operate or transport attachments which
are not attached completely.
A Always replace damaged hardware
immediately.
(A) Hitch Pins
(B) Snapper Pins
To Next Page
