6
GL6000, GL7000, GL9000, GL11000, WSM
SPECIFICATIONS
SPECIFICATIONS
* Conversion Formula : HP = 0.746 kW, PS = 0.7355 kW
W1028103
Model GL6000-STD GL6000-AUS
Generator
Frequency 50 Hz
Rated output 5.5 kW
Maximum output 6.0 kW
Rated voltage 220 V 240 V
Rated current 25 A 22.9 A
Phrase and wire 1 - 2
Number of poles 2
Power Factor 1
Insulation Stator coil: B Rotor coil: F
Engine
Design Vertical, liquid cooled, 4 cycle, diesel
Model name Z482-E2B-SEC-2
Rated output 6.9 kW
Speed 3000 min
-1
(rpm)
Number of cylinder -
Bore x Stroke
2 - 67 x 68 mm (2 - 2.52 x 2.68 in.)
Displacement 0.479 L (29.23 cu.in.)
Fuel tank capacity 28 L (7.4 U.S.gals)
Crankcase oil capacity 2.2 L (0.58 U.S.gals)
Starting system Electric type 12 V / 0.8 kW
Battery 38B20R 12 V x 28 Ah / 5 Hr
Continuous operating hours (at rated load) 12 hrs
Net weight kg (lbs) 235 kg (518 lbs)
Output
Receptacle 6-15R 2 15A 2
Ter m ina l 2P –
