PERIODIC SERVICE92
EVERY 600 HOURS
BAdjusting Front Axle Pivot
If the front axle pivot pin adjustment is not correct, front
wheel vibration can occur causing vibration in the steering
wheel.
C Adjusting procedure
Loosen the lock nut, screw-in the adjusting screw until
seated, then tighten the screw with an additional 1/6 turn.
Re-tighten the lock nut.
BAdjusting King-pin Pivot
Loosen the lock nut and tighten the adjusting screw with
following torque:
BChanging Brake Oil
Consult your local KUBOTA Dealer for this service.
EVERY 1 000 HOURS
BChanging Transmission Fluid
To avoid personal injury or death:
A Allow engine to cool down sufficiently, oil can
be hot and can burn.
1. To drain the used oil, remove the drain plug at the
bottom of the transmission case and drain the oil
completely into the oil pan.
2. After draining reinstall the drain plug.
3. Fill with the new KUBOTA SUPER UDT fluid up to the
upper notch on the dipstick.
(See "LUBRICANTS, FUEL AND COOLANT" in
"MAINTENANCE" section.)
4. After running the engine for a few minutes, stop it and
check the oil level again; add oil to prescribed level.
(1) Adjusting screw
(2) Lock nut
Adjusting screw 4.9 to 9.8 N-m, 0.5 to 1.0 kgf-m
Lock nut 98.1 to 147 N-m, 10 to 15 kgf-m
(1) Adjusting screw
(2) Lock nut
Oil capacity 60 L
(1) Dipstick
(2) Oil inlet
(A) Oil level is acceptable within
this range.
(1) Drain plug
To Next Page
