2 SPECIFICATIONS
SPECIFICATIONS
SPECIFICATION TABLE
Model
M108S
4WD
Engine
Model V3800-DI-TI
Type Direct Injection, liquid cooled 4 cylinder diesel
Number of cylinders 4
Total displacement cm 3769
Bore and stroke mm 100 x 120
Rated speed rpm 2600
Net power *1 kW 77.2
PTO power *1 (factory observed) kW 69.4
Maximum torque N-m / rpm 355 / 1400 to 1600
Battery capacity 12V, RC: 160 min, CCA 900A
Fuel tank capacity L 175
Engine oil capacity L 10.7
Coolant capacity L 9.6
Dimensions
Overall length mm 4070
Overall width
(minimum tread)
mm 2010
Overall height mm 2680
Wheel base mm 2435
Tread
Front mm 1390 to 1690
Rear mm 1730 to 2035
Minimum ground clearance mm 435 (Drawbar bracket)
Weight kg 3510
Traveling
system
Standard
tire size
Front tires 340 / 85R24 (13.6R24)
Rear tires *2 480 / 70R34 (18.4R34)
Clutch Hydraulic wet disks
Steering Hydraulic Power Steering
Braking system Hydraulic wet disks
Differential
Bevel gears with diff. lock
(Front & Rear)
