3SPECIFICATIONS
Hydraulic
unit
Hydraulic control system Position, draft (top link sensing) & mix control
Pump capacity L / min 65
Three point hitch Category 2
Max. lifting force
At lifting
points *3
kg
2500,
3900 with 2 assist cylinders (option)
24 in. behind
lifting point *3
kg
2100,
3400 with 2 assist cylinders (option)
Remote hydraulic control
2 standard
(3rd & flow control valve optional)
System pressure
MPa
(kgf/cm )
19.6 (200)
Traction system Swinging drawbar, adjustable in direction
PTO
Live PTO
(Independent)
Direction of turning Clockwise, viewed from tractor rear
PTO/Engine
speed
rpm
540 / 2205
540E / 1519
The company reserves the right to change the specifications without notice.
NOTE: *1 Manufacturer's estimate
*2 with cast iron disks for rear wheels.
*3 At lower link end with links horizontal.
Model
M108S
4WD
