39PERIODIC SERVICE
5. To lower the cargo bed, raise the cargo bed slightly
using the handgrip.
6. Release the safety support from the latch slot by
pulling up on the middle of the support.
7. Put the safety support into the support holder.
8. Slowly lower the cargo bed onto the frame and set the
latches on both sides.
JACK-UP POINT
To avoid personal injury, death or vehicle damage:
A Do not work under the vehicle unless it is
secured by safe stands or suitable blocking.
BFront End
Jack up at the front bumper only.
BRear End
Jack up the rear side after placing a wooden block under
the transmission bottom cover for securing the engine and
then supporting it.
Do not jack it up supporting the steel plate portion under
the transmission bottom cover directly.
(1) Safety support
(2) Latch slot
(1) Support holder
(1) Front bumper
(2) Jack
(3) Wooden block
(1) Transmission bottom cover
(2) Jack
(3) Wooden block
