4-35
4.21. TRAILER SOCKET*
*
The trailer socket is located at the rear side of the vehicle.
It is only allowed to provide vehicle lighting on the trailer
4.21.1. Socket Wiring
Function Color
1 Brake Light G/Y
2 LH Turn O
3 Fog Light Signal L(1)
4 LH Indicator BR/R
5 RH Indicator BR/Y
6 RH Turn SB
7 Ground G
