EXHAUST COMPONENTS
Torque
Part Part Bolted To
ft-lb N-
m
Exhaust Pipe Engine 20 27
Spark Arrester Muffler
48
in.-lb
5.5
ELECTRICAL COMPONENTS
Coil Frame 12 16
Starter Motor Positive Cable Star t er Motor 8 11
STEERING COMPONENTS
Steering Post Bearing
Housing
Frame 20 27
Handlebar Cap Steering Post 20 27
Lower Steering Post Bearing
Cap
Screw
Steering
Post 40 54
Tie Rod End** Steering Post Arm 30 41
BRAKE COMPONENTS
Brake Disc* Hub 15 20
Brake Hose Caliper 20 27
Brake Hose Master Cylinder 20 27
Brake Hose
Auxiliary
Brake
Cylinder
20 27
Master Cylinder (Rear) Frame 8 11
Master Cylinder Clamp
Screws
(Front)
Master
Cylinder 5.5 8
Hydraulic Caliper Knuckle 20 27
CHASSIS COMPONENTS
Foo t rest Frame (8 mm) 20 27
Bumper Frame (10 mm) 35 47
SUSPENSION COMPONENTS (Front)
A-Arm Frame 35 47
Knuckle Ball Join t 35 47
Shock Absorber Frame 35 47
Shock Absorber Upper A-Arm 35 47
Knuckle A-Arm 35 47
SUSPENSION COMPONENTS (Rear)
Shock Absorber (Upper) Frame 35 47
Shock Absorber (Lower) Lower A-Arm 35 47
A-Arm Frame
35 47
Knuckle A-Arm 35 47
General S p ec ificatio ns*
CHASSIS
Brake Typ e
Hydraulic
w/Brake Lever Lock
and
Auxiliary Brake
Tire Size Front - 24 x 8-12
Rear
- 24 x 10-12
Tire I nflation Pressure 0.28 kg/cm² (4 psi)
MISCELLANY
Gas Tank Capacity (rated) 15.1 L (4.0 U . S . gal.)
Rear Drive Capacity 250 ml (8.5 fl oz)**
Front Differential Capacity 275 ml (9.3 fl oz)***
Engine Oil Capacity 3.3 L (3.5 U . S . qt) - Overhaul
2.8
L (3.0 U . S . qt) - Change
Gasoline (recommended) 87 Octane Regular Unleaded
Engine Oil (recommended)
KYMCO
Synthetic
Differential/Rear Drive Lubricant SAE Approved 80W-90 Hypoid
Drive Belt Width (minimum) 28.5 mm (1.12 in.)
Brake Fluid DOT 4
Taillight/Brakeligh t 12V/5W/21W
Headlight 12V/35W (4)
Specifications subject to change without notice.
**
One inch below plug threads.
***
At the plug threads.
