14. BATTERY/CHARGING SYSTEM/
A.C. GENERATOR
14-8
PEOPL E 12 5/150
Remove the cooling fan by removing the four
cooling fan attaching bolts.
Hold the flywheel with an universal holder.
Remove the flywheel nut.
Universal Holder
Remove the A.C. generator flywheel using the
flywheel puller.
Remove the woodruff key.
Flywheel Puller
Remove the A.C. generator wire connector.
Cooling Fan
Special
Special
Universal Holder
Flywheel Puller
A.C. Generator Wire
Connector
Bolts
