•Before running the engine, make sure that the working area is well-ventilated. Never run the en-
gine in a closed area. The exhaust contains poisonous carbon monoxide gas which may cause
death to people.
•Gasoline is extremely flammable and is explosive under some conditions. The working area
must be well-ventilated and do not smoke or allow flames or sparks near the working area or
fuel storage area.
SPECIFICATIONS
ENGINE
Throttle grip free play : 2_ 6mm
Spark plug gap : 0.6_ 0.7mm
Spark plug: Standard : NGK C7HSA
Valve clearance : IN: 0.12mm
EX: 0.12mm
Idle speed : 1700±100rpm
Engine oil capacity:
At disassembly : 0.91 liter
At change : 0.81 liter
Gear oil capacity :
At disassembly : 210cc
At change : 180cc
Cylinder compression ( 125/150 ) : ( 13/15 )kg/cm
2
Ignition timing : BTDC 15°~28°±2°/1700±100rpm
BODY
Front brake free play: 10_ 20mm
Rear brake free play: 10_ 20mm
TIRE PRESSURE
