KYMCO PEOPLE 150 User Manual

3. INSPECTION/ADJUSTMENT
3-7
PEOPL E 12 5/150
FINAL REDUCTION GEAR OIL
OIL LEVEL CHECK
Stop the engine and remove the oil check bolt.
The oil level shall be at the oil check bolt hole.
If the oil level is low, add the recommended
oil to the proper level.
Recommended Oil:
GEAR OIL VISCOSITY SAE90#
Install the oil check bolt.
OIL CHANGE
Remove the oil check bolt.
Remove the oil drain bolt and drain the oil
thoroughly.
Install the oil drain bolt.
Torque: 1.0kg-m
Fill with the recommended oil.
Oil Capacity:At disassembly : 210cc
At change : 180cc
Reinstall the oil check bolt and check for oil
leaks.
Torque: 1.2kg-m
DRIVE BELT
Remove the left crankcase cover. (
!
9-3)
Inspect the drive belt for cracks or excessive
wear.
Replace the drive belt with a new one if nec-
essary and in accordance with the Mainte-
nance Schedule.
BRAKE SHOE
Drive Belt
Oil Check Bolt
Was
Place the motorcycle on its main stand
on level ground for oil level check.
＊
Sealing Washer
Make sure that the sealing washer is in
good condition.
＊
Make sure that the sealing washer is in
good condition.
＊
Oil Check Bolt Hole
Was
Oil Drain Bolt
www.PlanDeGraissage.org

KYMCO PEOPLE 150 Specifications

General

Ignition	CDI
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Fuel Capacity	7.5 Liters
Wheelbase	1380 mm
Cooling System	Air Cooled
Starter	Electric
Transmission	CVT
