16. STARTING SYSTEM
16-9
PEOPL E 12 5/150
ASSEMBLY
Install the springs, plungers and rollers onto
the clutch body.
Install the clutch cover by aligning the clutch
cover anchor pin with the hole in the clutch
body. Apply locking agent to the threads of
the clutch cover bolts and tighten them.
Torque: 1.2kg-m
Apply engine oil to the needle bearing and
starter drive gear and then install them to the
clutch body.
INSTALLATION
Install the starter clutch onto the crankshaft.
Apply engine oil to the starter idle gear and
shaft and then install them.
Hold the starter drive gear with the universal
holder and tighten the starter clutch lock nut.
Torque: 9.5kg-m
Universal Holder
Install the right crankcase cover. (
!
4-7)
Special
Note that the lock nut is left threaded.
＊
Woodruff Key
Keyway
Clutch Body
Anchor Pin
Hole
Clutch Cover
