KYMCO PEOPLE 150 User Manual

5. FUEL SYSTEM
5-5
PEOPL E 12 5/150
Connect a hose to the fuel enriching circuit of
the carburetor. Connect the auto bystarter
yellow wire to the positive (+) terminal of a
battery and green wire to the negative (-)
terminal. Wait 5 minutes and blow the hose
with mouth or vacuum pump. If the passage
is blocked, the auto bystarter is normal.
Disconnect the auto bystarter from the
battery. Wait 30 minutes and blow the hose
with mouth or vacuum pump. If air can be
blown into the hose, the auto bystarter is
normal.
REMOVAL
Remove the set plate screws and set plate.
Remove the auto bystarter from the
carburetor.
AUTO BYSTARTER INSPECTION
Check the auto bystarter valve and needle for
nicks, wear or damage.
If any faulty part is found, replace the auto
bystarter as a set.
INSTALLATION
Insert the auto bystarter into the carburetor
body until it bottoms.
Position the set plate into the groove in the
auto bystarter and tighten the screws.
• Be sure to install the auto bystarter and
set plate properly.
• Install the set plate with its bottom
face facing down.
＊
Auto Bystarter
Screws
Bystarter Needle
Bystarter Valve
Auto Bystarter
Screws
Set Plate
Vacuum Pump
Adopter
www.PlanDeGraissage.org

KYMCO PEOPLE 150 Specifications

General

Ignition	CDI
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Fuel Capacity	7.5 Liters
Wheelbase	1380 mm
Cooling System	Air Cooled
Starter	Electric
Transmission	CVT
