KYMCO PEOPLE 150 User Manual

8. CYLINDER/PISTON
8-3
PEOPL E 12 5/150
SPECIFICATIONS
Item (125cc)
Standard (mm)
Service Limit (mm)
I.D.
52.400_ 52.410
52.50
Warpage
æ
0.05
Cylindricity
æ
0.05
True roundness
æ
0.05
Ring-to-groove
Top
0.015_ 0.055
0.09
clearance
Second
0.015_ 0.055
0.09
Top
0.10_ 0.25
0.5
Piston,
Ring end gap
Second
0.10_ 0.25
0.5
piston ring
Oil side rail
0.2_ 0.7
æ
Piston O.D.
52.370_ 52.390
52.3
Piston O.D. measuring position
9mm from bottom of skirt
æ
.
Piston-to-cylinder clearance
0.010_ 0.040
0.1
Piston pin hole I.D.
15.002_ 15.008
15.04
Piston pin O.D
14.994_ 15.000
14.96
Piston-to-piston pin clearance
0.002_ 0.014
0.02
Connecting rod small end I.D. bore
15.016_ 15.034
15.06
Item (150cc)
Standard (mm)
Service Limit (mm)
I.D.
57.405_ 57.415
57.50
Warpage
æ
0.05
Cylindricity
æ
0.05
True roundness
æ
0.05
Ring-to-groove
Top
0.015_ 0.055
0.09
clearance
Second
0.015_ 0.055
0.09
Top
0.15_ 0.30
0.5
Piston,
Ring end gap
Second
0.15_ 0.30
0.5
piston ring
Oil side rail
0.2_ 0.7
æ
Piston O.D.
57.370_ 57.390
57.3
Piston O.D. measuring position
9mm from bottom of skirt
æ
.
Piston-to-cylinder clearance
0.010_ 0.040
0.1
Piston pin hole I.D.
15.002_ 15.008
15.04
Piston pin O.D
14.994_ 15.000
14.96
Piston-to-piston pin clearance
0.002_ 0.014
0.02
Connecting rod small end I.D. bore
15.016_ 15.034
15.06
Cylinder
Cylinder
