－45－
(5) ENGINE OIL CHANGE
1.Place the scooter on its main stand on level ground.
2.Remove the oil dipstick.
3.Remove the drain bolt to drain the oil.
4.Refill fresh engine oil for 0.9 liter. Firmly tighten the oil
dipstick.
5.Warm up the engine and check the oil level again after
the engine is stopped for 20 30 seconds.
Specified Oil: SAE15W40
Capacity/Exchanging Capacity:1.1L/0.9L
～
When changing the engine oil, also clean the oil
strainer and reinstall it.
Use the specified engine oil.
Change engine oil at first 300km and then change it
at every 2000km.
Engine oil will deteriorate easily and require more
frequent change if the scooter is often ridden in
dusty and cold areas or ridden for short distance.
Do not mix engine oil of different classes or viscosities.
It may cause damage to engine.
CAUTION:
Drain boltDrain bolt
