Kyocera AK-730 User Manual

3NC/3NB/3NK
1-2-3
Bridge unit
Figure 1-2-2
See the Installation Guide for installation.
3
2
6
5
8
4
7
9
18 19 20 21 22
14
15
16
17
13 12 11 10
23
1
1. Outer case
2. Bottom spacer
3. Bridge conveying unit
4. Bridge entry unit
5. Bridge drive unit
6. Bridge eject unit
7. Spacer A
8. Spacer B
9. Top spacer
10. Left connevtion cover
11. Upper front cover
12. Left scanner cover
13. Lower connevtion
cover
14. Left cover
15. Front left stay
16. Rear left stay
17. Upper left cover
18. Edging
19. Wire stopper
20. M4 x 8 screw
21. M4 x 20 screw
22. P Tite screw M3 x 8
23. Installation guide,etc.
