Kyocera AK-730 User Manual

3NC/3NB/3NK
2-3-2
YC7
1 GND - - Ground
Connected to
machine
2 GND - - Ground
3 ENG RDY O 0/3.3 V DC Ready signal to the machine
4 ENG SEL I 0/3.3 V DC Select signal from the machine
5 ENG CLK I 0/3.3 V DC(pulse) Serial communication clock signal
6 ENG DI I 0/3.3 V DC(pulse) Serial communication data signal
input
7 ENG DO O 0/3.3 V DC(pulse) Serial communication data signal
output
YC8
1 5V O 5 V DC 5 V DC power output
Connected to
the Punch
unit PWB
2 3.3V O 3.3 V DC 3.3 V DC power output
3 3.3V O 3.3 V DC 3.3 V DC power output
4 GND - - Ground
5 NC - - Not used
6 EDGE DET REM I 0/3.3 V DC PUPES: On/Off
7 PUN MOT REM O 0/3.3 V DC PUM: On/Off
8 PU RDY I 0/3.3 V DC Ready signal
9 PU SEL O 0/3.3 V DC Select signal
10 PU CLK O 0/3.3 V DC(pulse) Serial communication clock signal
11 PU DI I 0/3.3 V DC(pulse) Serial communication data signal
input
12 PU DO O 0/3.3 V DC(pulse) Serial communication data signal
output
YC9
1 GND - - Ground
Connected to
the Punch
unit PWB
2 24V2 O 24 V DC 24 V DC power output
YC10
1 EJECT MOT 2B O 0/24 V DC(pulse) DFEM drive control signal
Connected to
the DF eject
motor,DF mid-
dle eject
motor ,DF
middle motor,
DF eject
release
motor,DF slide
motor.
2 EJECT MOT 1B O 0/24 V DC(pulse) DFEM drive control signal
3 EJECT MOT 2A O 0/24 V DC(pulse) DFEM drive control signal
4 EJECT MOT 1A O 0/24 V DC(pulse) DFEM drive control signal
5 MIDDLE MOT 2B O 0/24 V DC(pulse) DFMM drive control signal
6 MIDDLE MOT 1B O 0/24 V DC(pulse) DFMM drive control signal
7 MIDDLE MOT 2A O 0/24 V DC(pulse) DFMM drive control signal
8 MIDDLE MOT 1A O 0/24 V DC(pulse) DFMM drive control signal
9 ENTRY MOT 2B O 0/24 V DC(pulse) DFPEM drive control signal
10 ENTRY MOT 1B O 0/24 V DC(pulse) DFPEM drive control signal
11 ENTRY MOT 2A O 0/24 V DC(pulse) DFPEM drive control signal
Connector Pin Signal I/O Voltage Description
