Using Optional Equipment
97
To edit cover printing options:
1From the Media for Cover list, select the media type or source cassette for the front and
back covers. When you choose the media type, a source cassette matching that media is
automatically selected.
Heavy, thin, or other special papers must be supplied from the multi-purpose tray.
2Click
OK to return to the Media dialog box.
3 Load the paper for the front and back cover in the paper cassette selected in step 1.
4Click
OK to return to the Print dialog box
5Click
OK to start printing.
Page Insert You can insert a preprinted page or a page of a different paper type before a designated page.
You can also print on the inserted paper. If a duplex unit is installed, you can also print on the
reverse of the inserted paper.
Although the
Page Insert and Cover mode may be used simultaneously, they cannot be
combined with the
Transparency Interleaving described in Transparency Interleaving on
page 100.
Insert Page Printing
1 From the application’s Print dialog box, access the printer Properties. (Select Print from
the
File menu and select Properties).
NOTE
Media type selections are not supported for the following models:
KM-1510, KM-1530, KM-1810, KM-4230, KM-5230, and KM-6230.
