Kyocera PF-1100 User Manual

2RV/2RW/2RX/2RY/3RA-3
7-6
(1-4) Vertical streaks or bands
(1-5) Center of the original and output image is inconsistent
(1-6) Irregular error in the leading edge between original and output image (variation
in the paper leading edge timing)
Step Check description Assumed cause Measures Reference
1 Changing the settings The media type is not
properly set.
Select the proper media type
in the system menu.
2 Cleaning the FD guide The FD guide is dirty with
toner or toner adheres to it.
Clean the FD guide.
3 Cleaning the separation
needle
The separation needles
are dirty with paper dust or
toner.
Clean the separation needle
at the transfer/separation
section with a cleaning blush.
4 Checking the transfer roller The transfer roller is dirty,
deformed or worn down.
Clean the transfer roller if the
image failure appears in the
circumference interval. If not
repaired, replace the transfer
roller.
Step Check description Assumed cause Measures Reference
1 Re-setting the guide The guide is not aligned to
the paper size.
Align the paper width guide,
paper guide (MP tray) or PF
paper width guide (paper
feeder) to the paper size and
re-load paper.
2 Executing U034 The center line is not
adjusted properly.
Adjust the center line in U034
[LSU Out Left].
Step Check description Assumed cause Measures Reference
1 Executing U034 The leading edge timing is
not properly adjusted.
Adjust the leading edge tim-
ing at U034 [LSU Out Top].
2 Checking the feed clutch
and registration clutch
The feed clutch and regis-
tration clutch operation is
faulty.
Reattach the feed clutch and
registration clutch and recon-
nect the connectors. If not
repaired replace them.

Kyocera PF-1100 Specifications

General

Style	Desktop
Color	White
Control Panel	7 Color LED
Noise Level	Print mode: 51dB(A); Silent mode: 47dB(A); Stand-by mode: 29dB(A)
Ready: 30 dBA	-
Interface Connectors	USB 2.0 High Speed x1; Ethernet 10BASE-T/100BASE-TX/1000BASE-T; USB Host x1
Wireless Connectivity	-
OS Compatibility	Windows Server 2003
Windows Server 2012 R2	Windows Vista
Apple Macintosh OS X 10.5 or later; Linux	Mac OS 10.10.x
Windows 8.x (32-bit	64-bit)
Windows 7 (32-bit	64-bit)
Windows Vista® (32-bit	64-bit)
Mac OS® X 10.6.8 – 10.10.x8	Windows Server 2003
Windows Server 2008 R2	Windows Server 2012
Windows Vista	Windows 7
Windows 8.1	Windows 10; Linux
2012/ 2008R2 / 2008 / 2003	Mac OS® X
10.6 - 10.10	Various Linux® / Unix®
	Windows 7 SP1 / Windows 8.1 / Windows 10 / Windows 11
Paper Capacity	Standard: 250 sheets x1 (Cassette) + 100 sheets (MPT)
Maximum: 850 sheets (Main Unit + PF-1100 x2 + MPT)	100 Sheets Standard
Dedicated Photo Tray: 20 sheets Premium Photo Paper Glossy	Standard: 250 sheets (Cassette) + 50 sheets (MPT)
Maximum: 550 sheets (Main Unit + 250 sheets PF-5110 + MPT)	Standard: 100 sheets
Output: 30 sheets	350 Sheets / 850 Sheets
Maximum: 2	300-Sheet Cassette Tray (550 SCT + 100
Multipurpose Tray: 100-Sheet MP Tray (@80 gsm)	Output: 50 Sheets
Paper Tray: 100 Sheets Standard	30 Photo Sheets
Paper Size	Cassette: Min. A6R - Max. A4R (Legal)
MPT: Min. A6R - Max. A4R (Legal)	A4 (21.0x29.7 cm)
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	A4; Photo: 4 x 6"" (10.2 x 15.2 cm)
MPT: Min. A6R – Max. A4 (Legal)	Letter A Size (8.5 in x 11 in)
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	A3+
Manual Feed Slot: Letter	A4
Paper Weight	Cassette: 60 - 163 g/m2
MPT: 60 - 220 g/m2	-
MPT: 16 lb Bond - 120 lb Index (60 - 220gsm)	Cassette: 60 - 163 g/ (16 - 43 lb)
Duplex Printing: 60 - 120 g/m2 (16 - 32 lb)	-
Functions	-
Features	Compact design/Top-class silent design
Printing Method	Semiconductor Laser
Nozzles	-
Piezo with 70 nozzles x 3	-
Print Speed	35 ppm (A4)
-4"" x 6"" borderless photo in as fast as 20 seconds (Draft Mode)1	21/21 ppm (A4 Mono/Color)
up to 4 ppm - color duplex	Letter: 37 ppm; Legal: 30 ppm
Speed (Duplex) Up to 20 ipm in A4 (Up to 20 ipm in Letter)	Printing Speed ISO/IEC 24734: 2.6 pages/min Monochrome
Maximum Printing Speed: 15 pages/min Monochrome (plain paper 75 g/m²)	15 pages/min Colour (plain paper 75 g/m²)
First Page Print Time	6.8 seconds
From Sleep: As fast as 18.5 sec	-
Warm Up Time	15 seconds
10 Seconds or Less From Sleep	17 sec
Print Resolution	600 x 600 dpi
Scanner Type	-
Scan Speed	-
300 DPI 9	5 msec/line; 600 DPI 14
Color 35 ipm / 60 ipm (@ 300 dpi)	-
Scan Resolution	-
Enhanced Up to 4	800 x 4
Up to 1200 × 2400 dpi (optical)	-
Scan Formats	-
Copy Modes	-
Copy Speed	-
Color: 7.2 cpm	-
up to 3.8 ppm - color	-
MDMC Up to 35 cpm in A4 (Up to 36 cpm in Letter)	-
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	620W (Print Mode)
Sleep Mode: 0	8W - 0
<1.21 W)	-
Power Off: Approx. 0.2 W	2 W
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	393 mm
Height	272 mm
Width	375 mm
Net Weight	Approx. 14.0 kg
