Kyocera PF-1100 User Manual

2RV/2RW/2RX/2RY/3RA-3
7-9
(1-14) Toner smudge at the paper edge
(1-15) Dirty reverse side
(1-16) Offset image
Step Check description Assumed cause Measures Reference
1 Cleaning the conveying
guide
The conveying guide is
dirty with toner.
Clean the conveying guide,
developer unit and developer
duct.
Step Check description Assumed cause Measures Reference
1 Checking the transfer roller The transfer roller is dirty
or scratched.
Clean the transfer roller if the
image failure appears in the
circumference interval. If not
repaired, replace the transfer
roller.
2 Cleaning the fuser press
roller
The fuser press roller is
dirty depending on media
type selection.
Clean the fuser press roller.
Next, select the proper media
type in the system menu.
3 Checking the conveying
guide and the developer
unit
The conveying guide or
developer unit is dirty.
Clean the conveying guide
and developer unit.
Step Check description Assumed cause Measures Reference
1 Checking the paper Unspecified papers are
used.
Replace with paper within
specification or set media
type to the closest one.
2 Changing the settings The media type is not
properly set.
Change the setting depend-
ing on the paper type and
weight.
3 Cleaning the transfer roller The transfer roller is dirty. Clean the transfer roller if the
image failure appears in the
circumference interval.
4 Cleaning the fuser belt The fuser belt is dirty. Clean the fuser belt if the
image failure appears in the
circumference interval.
5 Replacing the high voltage
PWB
The high voltage PWB is
faulty.
Replace the high voltage
PWB.
6 Replacing the fuser unit The fuser belt surface is
scratched.
Replace the fuser unit.

Kyocera PF-1100 Specifications

General

Style	Desktop
Color	White
Control Panel	7 Color LED
Noise Level	Print mode: 51dB(A); Silent mode: 47dB(A); Stand-by mode: 29dB(A)
Ready: 30 dBA	-
Interface Connectors	USB 2.0 High Speed x1; Ethernet 10BASE-T/100BASE-TX/1000BASE-T; USB Host x1
Wireless Connectivity	-
OS Compatibility	Windows Server 2003
Windows Server 2012 R2	Windows Vista
Apple Macintosh OS X 10.5 or later; Linux	Mac OS 10.10.x
Windows 8.x (32-bit	64-bit)
Windows 7 (32-bit	64-bit)
Windows Vista® (32-bit	64-bit)
Mac OS® X 10.6.8 – 10.10.x8	Windows Server 2003
Windows Server 2008 R2	Windows Server 2012
Windows Vista	Windows 7
Windows 8.1	Windows 10; Linux
2012/ 2008R2 / 2008 / 2003	Mac OS® X
10.6 - 10.10	Various Linux® / Unix®
	Windows 7 SP1 / Windows 8.1 / Windows 10 / Windows 11
Paper Capacity	Standard: 250 sheets x1 (Cassette) + 100 sheets (MPT)
Maximum: 850 sheets (Main Unit + PF-1100 x2 + MPT)	100 Sheets Standard
Dedicated Photo Tray: 20 sheets Premium Photo Paper Glossy	Standard: 250 sheets (Cassette) + 50 sheets (MPT)
Maximum: 550 sheets (Main Unit + 250 sheets PF-5110 + MPT)	Standard: 100 sheets
Output: 30 sheets	350 Sheets / 850 Sheets
Maximum: 2	300-Sheet Cassette Tray (550 SCT + 100
Multipurpose Tray: 100-Sheet MP Tray (@80 gsm)	Output: 50 Sheets
Paper Tray: 100 Sheets Standard	30 Photo Sheets
Paper Size	Cassette: Min. A6R - Max. A4R (Legal)
MPT: Min. A6R - Max. A4R (Legal)	A4 (21.0x29.7 cm)
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	A4; Photo: 4 x 6"" (10.2 x 15.2 cm)
MPT: Min. A6R – Max. A4 (Legal)	Letter A Size (8.5 in x 11 in)
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	A3+
Manual Feed Slot: Letter	A4
Paper Weight	Cassette: 60 - 163 g/m2
MPT: 60 - 220 g/m2	-
MPT: 16 lb Bond - 120 lb Index (60 - 220gsm)	Cassette: 60 - 163 g/ (16 - 43 lb)
Duplex Printing: 60 - 120 g/m2 (16 - 32 lb)	-
Functions	-
Features	Compact design/Top-class silent design
Printing Method	Semiconductor Laser
Nozzles	-
Piezo with 70 nozzles x 3	-
Print Speed	35 ppm (A4)
-4"" x 6"" borderless photo in as fast as 20 seconds (Draft Mode)1	21/21 ppm (A4 Mono/Color)
up to 4 ppm - color duplex	Letter: 37 ppm; Legal: 30 ppm
Speed (Duplex) Up to 20 ipm in A4 (Up to 20 ipm in Letter)	Printing Speed ISO/IEC 24734: 2.6 pages/min Monochrome
Maximum Printing Speed: 15 pages/min Monochrome (plain paper 75 g/m²)	15 pages/min Colour (plain paper 75 g/m²)
First Page Print Time	6.8 seconds
From Sleep: As fast as 18.5 sec	-
Warm Up Time	15 seconds
10 Seconds or Less From Sleep	17 sec
Print Resolution	600 x 600 dpi
Scanner Type	-
Scan Speed	-
300 DPI 9	5 msec/line; 600 DPI 14
Color 35 ipm / 60 ipm (@ 300 dpi)	-
Scan Resolution	-
Enhanced Up to 4	800 x 4
Up to 1200 × 2400 dpi (optical)	-
Scan Formats	-
Copy Modes	-
Copy Speed	-
Color: 7.2 cpm	-
up to 3.8 ppm - color	-
MDMC Up to 35 cpm in A4 (Up to 36 cpm in Letter)	-
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	620W (Print Mode)
Sleep Mode: 0	8W - 0
<1.21 W)	-
Power Off: Approx. 0.2 W	2 W
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	393 mm
Height	272 mm
Width	375 mm
Net Weight	Approx. 14.0 kg
