Kyocera PF-1100 User Manual

2RV/2RW/2RX/2RY/3RA-3
7-21
(2-10) The entire image is light
Step Check description Assumed cause Measures Reference
1 Reinstalling the toner con-
tainer
Toner is collected on one
side.
Sufficiently shake the toner
container and reinstall it to
the main unit.
2 Executing Drum refresh The drum surface has con-
densation.
Execute Drum refresh.
3 Replacing the toner con-
tainer
The toner supply opening
does not open.
Replace the toner container.
3 Replenishing toner in the
developer unit
Toner in the developer unit
is degraded due to many
low coverage prints.
Consume degraded toner in
the developer unit with test
prints and replenish the toner.
4 Reinstalling the drum unit
and developer unit
The drum unit or the devel-
oper unit is not properly
attached, so that the devel-
oper roller does not con-
tact the drum.
Reinstall the drum unit and
developer unit.
5 Correcting the developer
bias contact
The developer bias contact
is deformed.
Correct the developer bias
contact so that it surely
grounds.
6 Cleaning the DS pulley The DS pulleys are dirty. Clean the DS pulleys at both
ends of the developer unit.
7 Replacing the developer
unit
The DS pulleys are faulty. Replace the developer unit.
8 Replacing the drum unit The drum surface is worn
down.
Replace the drum unit.
9 Correcting the main char-
ger contact
The voltage impressed to
the main charger contact is
high.
Correct the main charger
contact for secure ground.
10 Checking the connection The FFC is not properly
connected or faulty.
Reconnect the FFC. If the
FFC terminal is peel,
deformed or broken, replace
it.
• LSU (APC PWB) - Main/
engine PWB (YC505)
11 Checking the connection The connector is not prop-
erly connected or the wire
is faulty.
Clean the terminal of the fol-
lowing wire connectors and
reconnect the connectors. If
there is no continuity, replace
the wire.
• High voltage PWB - Main/
engine PWB (YC16)
12 Replacing the high voltage
PWB
The high voltage PWB is
faulty.
Replace the high voltage
PWB.
13 Replacing the LSU The LSU is dirty or faulty. Replace the LSU.
14 Replacing the main/engine
PWB
The main/engine PWB is
faulty.
Replace the main/engine
PWB.

Kyocera PF-1100 Specifications

General

Style	Desktop
Color	White
Control Panel	7 Color LED
Noise Level	Print mode: 51dB(A); Silent mode: 47dB(A); Stand-by mode: 29dB(A)
Ready: 30 dBA	-
Interface Connectors	USB 2.0 High Speed x1; Ethernet 10BASE-T/100BASE-TX/1000BASE-T; USB Host x1
Wireless Connectivity	-
OS Compatibility	Windows Server 2003
Windows Server 2012 R2	Windows Vista
Apple Macintosh OS X 10.5 or later; Linux	Mac OS 10.10.x
Windows 8.x (32-bit	64-bit)
Windows 7 (32-bit	64-bit)
Windows Vista® (32-bit	64-bit)
Mac OS® X 10.6.8 – 10.10.x8	Windows Server 2003
Windows Server 2008 R2	Windows Server 2012
Windows Vista	Windows 7
Windows 8.1	Windows 10; Linux
2012/ 2008R2 / 2008 / 2003	Mac OS® X
10.6 - 10.10	Various Linux® / Unix®
	Windows 7 SP1 / Windows 8.1 / Windows 10 / Windows 11
Paper Capacity	Standard: 250 sheets x1 (Cassette) + 100 sheets (MPT)
Maximum: 850 sheets (Main Unit + PF-1100 x2 + MPT)	100 Sheets Standard
Dedicated Photo Tray: 20 sheets Premium Photo Paper Glossy	Standard: 250 sheets (Cassette) + 50 sheets (MPT)
Maximum: 550 sheets (Main Unit + 250 sheets PF-5110 + MPT)	Standard: 100 sheets
Output: 30 sheets	350 Sheets / 850 Sheets
Maximum: 2	300-Sheet Cassette Tray (550 SCT + 100
Multipurpose Tray: 100-Sheet MP Tray (@80 gsm)	Output: 50 Sheets
Paper Tray: 100 Sheets Standard	30 Photo Sheets
Paper Size	Cassette: Min. A6R - Max. A4R (Legal)
MPT: Min. A6R - Max. A4R (Legal)	A4 (21.0x29.7 cm)
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	A4; Photo: 4 x 6"" (10.2 x 15.2 cm)
MPT: Min. A6R – Max. A4 (Legal)	Letter A Size (8.5 in x 11 in)
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	A3+
Manual Feed Slot: Letter	A4
Paper Weight	Cassette: 60 - 163 g/m2
MPT: 60 - 220 g/m2	-
MPT: 16 lb Bond - 120 lb Index (60 - 220gsm)	Cassette: 60 - 163 g/ (16 - 43 lb)
Duplex Printing: 60 - 120 g/m2 (16 - 32 lb)	-
Functions	-
Features	Compact design/Top-class silent design
Printing Method	Semiconductor Laser
Nozzles	-
Piezo with 70 nozzles x 3	-
Print Speed	35 ppm (A4)
-4"" x 6"" borderless photo in as fast as 20 seconds (Draft Mode)1	21/21 ppm (A4 Mono/Color)
up to 4 ppm - color duplex	Letter: 37 ppm; Legal: 30 ppm
Speed (Duplex) Up to 20 ipm in A4 (Up to 20 ipm in Letter)	Printing Speed ISO/IEC 24734: 2.6 pages/min Monochrome
Maximum Printing Speed: 15 pages/min Monochrome (plain paper 75 g/m²)	15 pages/min Colour (plain paper 75 g/m²)
First Page Print Time	6.8 seconds
From Sleep: As fast as 18.5 sec	-
Warm Up Time	15 seconds
10 Seconds or Less From Sleep	17 sec
Print Resolution	600 x 600 dpi
Scanner Type	-
Scan Speed	-
300 DPI 9	5 msec/line; 600 DPI 14
Color 35 ipm / 60 ipm (@ 300 dpi)	-
Scan Resolution	-
Enhanced Up to 4	800 x 4
Up to 1200 × 2400 dpi (optical)	-
Scan Formats	-
Copy Modes	-
Copy Speed	-
Color: 7.2 cpm	-
up to 3.8 ppm - color	-
MDMC Up to 35 cpm in A4 (Up to 36 cpm in Letter)	-
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	620W (Print Mode)
Sleep Mode: 0	8W - 0
<1.21 W)	-
Power Off: Approx. 0.2 W	2 W
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	393 mm
Height	272 mm
Width	375 mm
Net Weight	Approx. 14.0 kg
