Kyocera PF-1100 User Manual

2RV/2RW/2RX/2RY/3RA-3
7-68
7-3Self diagnostic
(1) Self diagnostic function
This machine is equipped with a self-diagnostic function. When a problem is detected, the machine stops
operating and displays an error message on the operation panel. An error message consists of a message
prompting a contact to service personnel and a four-digit error code indicating the type of error.
(2) Self diagnostic codes
If the parts of the failure cause is not supplied, replace the unit that includes it.
Before attempting to check the fuser unit and the low voltage power supply PWB, be sure to turn the power
switch off and unplug the machine from power. (Allow at least 5 s before starting to conduct service until the
capacitors on the circuit boards have been completely discharged.)
(2-1) Error codes list
Error code Contents
C0100 Backup memory device error
C0120 MAC address data error
C0130 Backup memory reading/writing error
C0140 Backup memory data error
C0150 Engine EEPROM data error
C0160 Engine EEPROM data error
C0170 Charger count error
C0180 Machine serial number mismatch
C0190 Backup memory device error (Engine)
C0500 Drive lock detection by the engine firmware
C0510 High voltage remote control error
C0530 Backup task error
C0540 Engine firmware unexpected control detection
C0800 Print sequence error
C0840 RTC error ("Time for maintenance T" appears)
C0970 Power interruption detection
C1810 Paper feeder communication error (PF1)
C1820 Paper feeder communication error (PF2)
C2000 Main motor steady state error
C2010 Main motor startup error
C2600 PF feed motor error (PF1)
C2610 PF feed motor error (PF2)
C4000 Polygon motor startup error
C4010 Polygon motor steady-state error
C4201 Laser error
C6000 Broken fuser heater
C6020 Thermopile high temperature error

Kyocera PF-1100 Specifications

General

Style	Desktop
Color	White
Control Panel	7 Color LED
Noise Level	Print mode: 51dB(A); Silent mode: 47dB(A); Stand-by mode: 29dB(A)
Ready: 30 dBA	-
Interface Connectors	USB 2.0 High Speed x1; Ethernet 10BASE-T/100BASE-TX/1000BASE-T; USB Host x1
Wireless Connectivity	-
OS Compatibility	Windows Server 2003
Windows Server 2012 R2	Windows Vista
Apple Macintosh OS X 10.5 or later; Linux	Mac OS 10.10.x
Windows 8.x (32-bit	64-bit)
Windows 7 (32-bit	64-bit)
Windows Vista® (32-bit	64-bit)
Mac OS® X 10.6.8 – 10.10.x8	Windows Server 2003
Windows Server 2008 R2	Windows Server 2012
Windows Vista	Windows 7
Windows 8.1	Windows 10; Linux
2012/ 2008R2 / 2008 / 2003	Mac OS® X
10.6 - 10.10	Various Linux® / Unix®
	Windows 7 SP1 / Windows 8.1 / Windows 10 / Windows 11
Paper Capacity	Standard: 250 sheets x1 (Cassette) + 100 sheets (MPT)
Maximum: 850 sheets (Main Unit + PF-1100 x2 + MPT)	100 Sheets Standard
Dedicated Photo Tray: 20 sheets Premium Photo Paper Glossy	Standard: 250 sheets (Cassette) + 50 sheets (MPT)
Maximum: 550 sheets (Main Unit + 250 sheets PF-5110 + MPT)	Standard: 100 sheets
Output: 30 sheets	350 Sheets / 850 Sheets
Maximum: 2	300-Sheet Cassette Tray (550 SCT + 100
Multipurpose Tray: 100-Sheet MP Tray (@80 gsm)	Output: 50 Sheets
Paper Tray: 100 Sheets Standard	30 Photo Sheets
Paper Size	Cassette: Min. A6R - Max. A4R (Legal)
MPT: Min. A6R - Max. A4R (Legal)	A4 (21.0x29.7 cm)
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	A4; Photo: 4 x 6"" (10.2 x 15.2 cm)
MPT: Min. A6R – Max. A4 (Legal)	Letter A Size (8.5 in x 11 in)
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	A3+
Manual Feed Slot: Letter	A4
Paper Weight	Cassette: 60 - 163 g/m2
MPT: 60 - 220 g/m2	-
MPT: 16 lb Bond - 120 lb Index (60 - 220gsm)	Cassette: 60 - 163 g/ (16 - 43 lb)
Duplex Printing: 60 - 120 g/m2 (16 - 32 lb)	-
Functions	-
Features	Compact design/Top-class silent design
Printing Method	Semiconductor Laser
Nozzles	-
Piezo with 70 nozzles x 3	-
Print Speed	35 ppm (A4)
-4"" x 6"" borderless photo in as fast as 20 seconds (Draft Mode)1	21/21 ppm (A4 Mono/Color)
up to 4 ppm - color duplex	Letter: 37 ppm; Legal: 30 ppm
Speed (Duplex) Up to 20 ipm in A4 (Up to 20 ipm in Letter)	Printing Speed ISO/IEC 24734: 2.6 pages/min Monochrome
Maximum Printing Speed: 15 pages/min Monochrome (plain paper 75 g/m²)	15 pages/min Colour (plain paper 75 g/m²)
First Page Print Time	6.8 seconds
From Sleep: As fast as 18.5 sec	-
Warm Up Time	15 seconds
10 Seconds or Less From Sleep	17 sec
Print Resolution	600 x 600 dpi
Scanner Type	-
Scan Speed	-
300 DPI 9	5 msec/line; 600 DPI 14
Color 35 ipm / 60 ipm (@ 300 dpi)	-
Scan Resolution	-
Enhanced Up to 4	800 x 4
Up to 1200 × 2400 dpi (optical)	-
Scan Formats	-
Copy Modes	-
Copy Speed	-
Color: 7.2 cpm	-
up to 3.8 ppm - color	-
MDMC Up to 35 cpm in A4 (Up to 36 cpm in Letter)	-
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	620W (Print Mode)
Sleep Mode: 0	8W - 0
<1.21 W)	-
Power Off: Approx. 0.2 W	2 W
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	393 mm
Height	272 mm
Width	375 mm
Net Weight	Approx. 14.0 kg
