2RV/2RW/2RX/2RY/3RA-3
7-113
(8) Abnormal sound from the lower side than the fuser exit section
Friction sound between the lower exit roller bushing and stop ring due to adhesion of dirt and foreign objects
(9) Abnormal sound from the upper side of the fuser exit section
Friction sound between the lower exit pulley and shaft due to adhesion of dirt and foreign objects
(10)Abnormal sound from the fuser section
Dirt at the fuser section, foreign object adhesion, contact of parts
(11)Abnormal sound from inside the machine
Toner shutter open/close failure of the toner container, toner quantity lack, or toner aggregation
Step Check description Assumed cause Measures Reference
1 Cleaning and applying the
grease
The lower exit roller, bush-
ing, stop ring, etc. are dirty
or foreign objects adhere
to them.
Clean the lower exit roller,
bushing, stop ring, etc. and
apply heat-resistant grease.
2 Replacing the fuser unit The fuser unit is faulty. Replace the fuser unit.
Step Check description Assumed cause Measures Reference
1 Cleaning and applying the
grease
The pulley or the shaft is
dirty, or foreign objects
adhere on them.
Clean the lower exit roller and
shaft, and apply heat-resis-
tant grease.
2 Replacing the fuser unit The fuser unit is faulty. Replace the fuser unit.
Step Check description Assumed cause Measures Reference
1 Cleaning and applying the
grease
The bushing or the gear is
dirty or foreign objects are
on them.
Clean the fuser belt, fuser
press roller bushing and gear
and apply grease.
2 Cleaning and applying the
grease
The shaft is dirty or foreign
objects adhere to it.
Clean the lower exit roller and
shaft,etc., and apply heat-
resistant grease.
3 Cleaning and applying the
grease
The gear is dirty or foreign
objects adhere to it.
Clean the fuser drive gear
and apply the grease to it.
4 Applying the grease The grease is not enough. Apply the grease to the pres-
sure release cam and the
frame.
5 Replacing the fuser unit The fuser front guide is
warped and contacts the
fuser press roller.
Replace the fuser unit.
Step Check description Assumed cause Measures Reference
1 Checking the toner supply
opening
The spring to open/close
the toner shutter is caught
up or deformed.
Open and close the toner
supply opening manually to
fix the operation.

Kyocera PF-1100 Specifications

General

Style	Desktop
Color	White
Control Panel	7 Color LED
Noise Level	Print mode: 51dB(A); Silent mode: 47dB(A); Stand-by mode: 29dB(A)
Ready: 30 dBA	-
Interface Connectors	USB 2.0 High Speed x1; Ethernet 10BASE-T/100BASE-TX/1000BASE-T; USB Host x1
Wireless Connectivity	-
OS Compatibility	Windows Server 2003
Windows Server 2012 R2	Windows Vista
Apple Macintosh OS X 10.5 or later; Linux	Mac OS 10.10.x
Windows 8.x (32-bit	64-bit)
Windows 7 (32-bit	64-bit)
Windows Vista® (32-bit	64-bit)
Mac OS® X 10.6.8 – 10.10.x8	Windows Server 2003
Windows Server 2008 R2	Windows Server 2012
Windows Vista	Windows 7
Windows 8.1	Windows 10; Linux
2012/ 2008R2 / 2008 / 2003	Mac OS® X
10.6 - 10.10	Various Linux® / Unix®
	Windows 7 SP1 / Windows 8.1 / Windows 10 / Windows 11
Paper Capacity	Standard: 250 sheets x1 (Cassette) + 100 sheets (MPT)
Maximum: 850 sheets (Main Unit + PF-1100 x2 + MPT)	100 Sheets Standard
Dedicated Photo Tray: 20 sheets Premium Photo Paper Glossy	Standard: 250 sheets (Cassette) + 50 sheets (MPT)
Maximum: 550 sheets (Main Unit + 250 sheets PF-5110 + MPT)	Standard: 100 sheets
Output: 30 sheets	350 Sheets / 850 Sheets
Maximum: 2	300-Sheet Cassette Tray (550 SCT + 100
Multipurpose Tray: 100-Sheet MP Tray (@80 gsm)	Output: 50 Sheets
Paper Tray: 100 Sheets Standard	30 Photo Sheets
Paper Size	Cassette: Min. A6R - Max. A4R (Legal)
MPT: Min. A6R - Max. A4R (Legal)	A4 (21.0x29.7 cm)
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	A4; Photo: 4 x 6"" (10.2 x 15.2 cm)
MPT: Min. A6R – Max. A4 (Legal)	Letter A Size (8.5 in x 11 in)
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	A3+
Manual Feed Slot: Letter	A4
Paper Weight	Cassette: 60 - 163 g/m2
MPT: 60 - 220 g/m2	-
MPT: 16 lb Bond - 120 lb Index (60 - 220gsm)	Cassette: 60 - 163 g/ (16 - 43 lb)
Duplex Printing: 60 - 120 g/m2 (16 - 32 lb)	-
Functions	-
Features	Compact design/Top-class silent design
Printing Method	Semiconductor Laser
Nozzles	-
Piezo with 70 nozzles x 3	-
Print Speed	35 ppm (A4)
-4"" x 6"" borderless photo in as fast as 20 seconds (Draft Mode)1	21/21 ppm (A4 Mono/Color)
up to 4 ppm - color duplex	Letter: 37 ppm; Legal: 30 ppm
Speed (Duplex) Up to 20 ipm in A4 (Up to 20 ipm in Letter)	Printing Speed ISO/IEC 24734: 2.6 pages/min Monochrome
Maximum Printing Speed: 15 pages/min Monochrome (plain paper 75 g/m²)	15 pages/min Colour (plain paper 75 g/m²)
First Page Print Time	6.8 seconds
From Sleep: As fast as 18.5 sec	-
Warm Up Time	15 seconds
10 Seconds or Less From Sleep	17 sec
Print Resolution	600 x 600 dpi
Scanner Type	-
Scan Speed	-
300 DPI 9	5 msec/line; 600 DPI 14
Color 35 ipm / 60 ipm (@ 300 dpi)	-
Scan Resolution	-
Enhanced Up to 4	800 x 4
Up to 1200 × 2400 dpi (optical)	-
Scan Formats	-
Copy Modes	-
Copy Speed	-
Color: 7.2 cpm	-
up to 3.8 ppm - color	-
MDMC Up to 35 cpm in A4 (Up to 36 cpm in Letter)	-
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	620W (Print Mode)
Sleep Mode: 0	8W - 0
<1.21 W)	-
Power Off: Approx. 0.2 W	2 W
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	393 mm
Height	272 mm
Width	375 mm
Net Weight	Approx. 14.0 kg
