29
6 Commissioning
6.2 Installation
WARNING!
Danger of falling!
The mounted probe may not be used as a step. The maximum permissible bending moment
lies at 100 kg. In case of non-observance, the probe can be destroyed.
A fall can result in severe injury or death.
Do not step on the probe! Use appropriate work equipment.
NOTICE
Do not pull on cables or pneumatic connections. The maximum permissible tensile force lies
at 10 kg.
NOTICE
The maximum distance between LT3-F and combination probe KS1D may not exceed 10 m.
With longer distances the approval of the system for continuous operation expires.
For distances longer than 10 m the risk of EMC increases.
LAMTEC assumes no responsibility for correct, error-free functions.
6.3 Measurement Start-up
NOTICE
If it is not possible to switch off the system, the probe can be installed only after a successful
offset calibration and the GED has been aligned.
Commissioning the probe
1. Connect the probe electrically.
2. Switch on the voltage.
3. Enter the password for access level 2 (Service); see Chapter 6.3.1 Enter the Password for
the Access Level.
4. Activate maintenance mode; see Chapter 6.3.2 Activate/deactivate Maintenance Mode.
5. Heat up the probe (10 min. cold start and 30 min. faultless measurement operation)
6. Cold start is displayed.
7. The device automatically changes over to measurement operation.
8. The probe voltages stabilised to (-20 ... + 10mV).
9. The internal resistance stabilised to 15 ... 25 W
10. Calibrate the probe; see Chapter 6.4 Calibrating the Probe.
